Mature, professional technology with more than three years of development time
Extremely large, protected settlement surface for micro-organisms (806 m²/m³)
Innovative bypass technology for optimal movement of the Hel-X bio-elements
Removal of toxins, such as ammonium / ammonia, nitrite and nitrate
50 l Hel-X decompose approx. 340 g of fish food per day (can be extended to 75 l / module).
Aerator bar for oxygen enrichment and turbulence already installed
Permanent, optimal oxygen supply; self-cleaning effect from dead biomass
Pulling the slide valve flushes the debris out via a DN 75 discharge
Highly effective decomposition of pollutants and nutrients thanks to professional filter media in the fluidised bed process
Innovative and reliable product »Made in Germany«
Highly effective at breaking down pollutants and nutrients using purpose-designed filter media in the moving bed process (Moving Bed module)

TECHNICAL DATA

Dimensions (L x W x H)	mm	830 x 600 x 820
Net weight	kg	44.00
Guarantee (+ request guarantee) *	Years	2 + 1
Biological filter surface	m²	47.8
Biological filter surface protected	m²	40.3
Temperature display		No
Material		GRP Duroplast
Number of inlets	Units	2
Inlet connections	mm	180
Inlet connections		180 mm
Number of outlets	Units	2
Outlet connections		DN 150
Sludge discharge connections		DN 75
Connection to		AquaOxy CWS 2000 – 4800
Min. flow rate	l/h	10000
Max. flow rate	l/h	33000
Installation height above water level	cm	11.5
Type of use		Gravity fed system, Pump fed system
Other		Aeration pre-installed incl. 50l Hel-X 13 Biomedia Pollutant discharge incl. slide valve

SPARE PARTS

POS.	PRODUCT	SKU	QUANTITY
1	ASM lid container M / L	72780	1
2	Hel-X 13 Biomedia 25 l	42904	2
3	Oval head screw V2A DIN 7985 M6 x 12	20292	4
4	Fiberplate DIN 7603 6 x 12 x 1 mm	20609	1
5	Container bio module	17038	1
6	Cap nut V2A DIN 1587 M6	6117	1
7	Airstone clamp bio filter	17216	1
8	Oval head screw V2A DIN 7985 M6 x 25	17918	1
9	Air stone ProfiClear Premium Moving Bed	17391	1
10	PVC air hose transp. DI 9 mm x 0.85 m	18184	1
11	Air connection ProfiClear Compact	42865	1
12	Hose adapter 4 to 8 mm	17631	1
13	Air connection T-piece 9 mm	18186	1
14	PVC air hose transp. DI 9 mm x 0.10 m	18185	1
15	Oval head screw CZ-V2A DIN 7981 6.3 x 32	27572	1
16	Gasket mesh tube	17248	1
16	Gasket mesh tube 2016	43756	1
17	Outlet 150/1 ProfiClear M 2 – M 5	26958	1
18	Perforated sheet outlet	17327	1
19	Spare drain DN75 Premium	18446	1
20	Spare srews set drain DN75 Premium	18448	1
21	ASM rubber bushing D178 mm	17251	2
22	Outlet 150/2 ProfiClear M 2 – M 5	26987	2
23	ASM mesh tube bio module	19006	1
24	Mesh tube bracket	43353	1
